How to solve the warp problem in injection molding

Cause 1.
The part is too hot when ejected from the mold

Solution:

1. Lower the plastic mold temperature;
2. Lower the melt plastic temperature;
3. Prelong the mold open time.

Cause 2.
The melt plastic with low temperature

Solution:

1. Increase the plastic mold temperature;
2. Increase the barrel temperature;

Cause 3.
The uneven wall thickness or uncommon profile

Solution:

1. Even mold temperature;
2. Even the part wall thickness;

Cause 4.
Too much feeding

Solution:

1. Decrease the feeding;
2. Decrease the injection pressure;

Cause 5.
More than 1 gate,and each gate with uneven filling

Solution:

1. limit the main gate filling near the main runner;

Cause 6.
Bad ejection system

Solution:

1. Improve and redesign the ejection system;

Cause 7.
Uneven mold temperature

Solution:

1. Make the plastic mold temperature even
